3021 Phenolic Paperboard

Our 3021 Phenolic Paperboard is a budget-friendly insulation board. It uses insulation paper as the base material. It uses phenolic resin as the binder. The color is brown. The surface has a shiny look. 3021 is the Chinese national standard number. What is the difference between 3021 and 3240? 3240 is glass cloth epoxy board. It has high strength but a higher price. Our 3021 Phenolic Paperboard is paper-based. It has lower strength but a much lower price. The breakdown voltage and insulation resistance are still good enough for many applications. A low-voltage electrical factory came to us. They needed insulation shims with 1 mm thickness. The quantity was large. They used 5000 pieces every month. Before, they used 3240. The cost was too high. We recommended our 3021 Phenolic Paperboard. The price was half. The breakdown voltage was 10 kV. Their low-voltage equipment only runs at 690 V. That was more than enough. They switched to our 3021 Phenolic Paperboard. They saved 80,000 RMB a year.

The performance of our 3021 Phenolic Paperboard is as follows. Bending strength in the machine direction is 120 MPa. In the cross direction, it is 100 MPa. Breakdown voltage in the vertical direction is 12 kV. Water absorption is less than 2%. Temperature class is E (120°C). The machining property is good. Drilling does not cause delamination. Our special advantage is that we can make very thin 3021 Phenolic Paperboard. Thickness from 0.3 mm to 0.8 mm. Many factories cannot make it that thin. We have special presses. The thickness tolerance is ±0.05 mm. We support OEM. You tell us the size. We cut it for you. We can also punch it into shapes. MOQ is 500 kg. Free samples are available.
