Cord Wrapper For Appliances

Cord Wrapper For Appliances
Product Introduction:
Our cord wrapper for appliances is an electrical insulation paper. It is made from high-purity wood pulp. The color is light yellow. The surface is very smooth. Its main use is to wrap around wires and cables. That is why it is called cable paper. What is the difference between our cord wrapper for appliances and ordinary paper? Ordinary paper contains lignin and acidic substances. These can corrode copper wires.
Send Inquiry
Description
Technical Parameters

Pure Cellulose Paper That Won't Corrode Copper



Our cord wrapper for appliances is an electrical insulation paper. It is made from high-purity wood pulp. The color is light yellow. The surface is very smooth. Its main use is to wrap around wires and cables. That is why it is called cable paper. What is the difference between our cord wrapper for appliances and ordinary paper? Ordinary paper contains lignin and acidic substances. These can corrode copper wires. Our product is purified. The pH is neutral. It does not corrode conductors. Also, the tensile strength of our cord wrapper for appliances is three times that of ordinary paper. A power cord factory came to us. They export products to Europe. European regulations require RoHS and REACH compliance. Their previous cable paper supplier could not provide these certificates. We provided our cord wrapper for appliances. We have RoHS test reports. All passed. They have been buying from us for two years now. They purchase 3 tons every month.

product-800-800
product-800-600

Different Weights for Different Wire Sizes



Our annual capacity is 1000 tons. We can make our cord wrapper for appliances in different basis weights. The range is 80 g/m² to 200 g/m². Lower weight means thinner paper. Thinner paper is better for wrapping fine wires. We test every batch for tensile strength, elongation, and breakdown voltage. The breakdown voltage reaches above 8 kV. The tensile strength reaches above 6 kN/m. We have third-party test reports. We can provide them to your customer if needed. We supply our cord wrapper for appliances in rolls. The roll width can be from 10 mm to 1600 mm. We can also supply sheets. MOQ is 500 kg. Free samples are available in small amounts.

Used in Power Cords and Transformer Coils



Our cord wrapper for appliances is used in power cord wrapping insulation, transformer coil wrapping, motor lead wire insulation, home appliance internal wiring, and various wire and cable insulation layers. Below are the specifications.



Parameter

Value

Max finished width

1600 mm

Basis weight range

80 – 200 g/m²

Thickness range

0.08 – 0.25 mm

Temperature class

A (105°C) – E (120°C)



We support OEM. Our payment term is 30% deposit and 70% before shipment. Let us help you supply certified, safe cable paper to your customers.
